5 Port 10Gigabit Unmanaged Industrial Ethernet Switch

Standard & Protocol

IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX

IEEE 802.3ab for 1000Base-T

IEEE 802.3ae for 10GBase-T

Interface

Gigabit copper port: 10/100/1000Base-T(X), RJ45, Automatic Flow Control, Full/Half Duplex Mode Self-adaption, MDI/MDI-X Autotunning

10Gigabit copper port: 10/100/1000/10000Base-T(X), RJ45, Automatic Flow Control, Full/Half Duplex Mode Self-adaption, MDI/MDI-X Autotunning

Indicator

Running Indicator, Port Indicator, Power Supply Indicator

Switch Property

Transmission mode: store and forward

MAC address: 16K

Packet buffer size: 2Mbit

Backplane bandwidth: 28G

Switch time delay: <10μs

Power Supply

Voltage range: 24VDC (12~36VDC)

Power supply protection: anti-reverse protection, overload protection

Access terminal: 3-pin 5.08mm pitch terminal blocks

Power Consumption

No-load: 3.6W@24VDC

Full-load: 7.7W@24VDC

Working Environment

Operating temperature: -40~75℃

Storage temperature:-40~85℃

Relative humidity: 5%～95% (no condensation)

Physical Characteristic

Housing: IP30 protection, metal

Installation: wall mounting

Weight: 590g

Dimension (W x H x D): 162mm×110mm×36mm

Industrial Standard

IEC61000-4-2 (ESD), Level 3

Air discharge:± 8KV

Contact discharge: ±6KV

IEC61000-4-4 (EFT)，Level 3

Power supply: ±2kV

Ethernet port: ±2kV

IEC61000-4-5 (Surge)，Level 3

Power supply: common mode±2kV, differential mode±1kV

Shock: IEC 60068-2-27

Free fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

Authentication

CE, FCC, RoHS

Warranty

5 years
